EVO VISTAlens Safety Helmet with Integrated Eyewear - Vented

Product Features

  • Conforms to EN 397 and EN 50365 industrial helmet standards
  • Integrated optical class 1 overspec with B-rated impact resistance
  • Anti-scratch (K-rated) and anti-mist (N-rated) lens coatings
  • UV protection with 2C-1.2 lens marking for unimpaired color perception
  • Vented design for increased airflow and comfort
  • Revolution Flex wheel ratchet harness for easy adjustment and secure fit
  • Chamlon sweatband with Egyptian cotton core for maximum absorption
  • Safety cell concept prevents debris from reaching the scalp
  • Compatible with prescription eyewear
  • Universal slots for compatibility with various accessories
  • Available in multiple colors to suit organizational requirements

Product Description

The EVO VISTAlens Safety Helmet is a next-generation, feature-rich safety helmet based on proven Evolution head protection technology. It incorporates a fully retractable optical class 1 integrated overspec with B-rated impact resistance, ensuring that eye protection is always on hand when required. The vented design increases comfort by allowing cooling airflow, reducing helmet temperatures by an average of 2-3 degrees Celsius.

The integrated eyewear is easy to deploy, adjust, and maintain, providing high optical quality with no distortion. The anti-scratch (K-rated) and anti-mist (N-rated) coatings enhance durability and visibility in various working conditions. The UV protection with 2C-1.2 lens marking ensures unimpaired color perception and high light transmission.

The helmet features the Revolution Flex wheel ratchet harness, allowing for easy adjustment and a secure fit. The Chamlon sweatband, with its Egyptian cotton core, offers maximum absorption, maintaining comfort during extended use. The safety cell concept prevents ricocheting debris from reaching the scalp, enhancing overall safety.

Designed for compatibility, the EVO VISTAlens allows the wearers prescription glasses to be worn comfortably underneath the integrated overspec, reducing cost and ensuring optimum protection and vision. The universal slots enable the attachment of various accessories, enhancing versatility on the job.

Product Specifications

Specification Details
Shell Material High-Density Polyethylene (HDPE)
Harness System 6-point textile cradle
Adjustment Mechanism Revolution Flex Wheel Ratchet
Sweatband Chamlon with Egyptian cotton core
Standards Compliance EN 397, EN 50365 (Helmet); EN 166, EN 170 (Eyewear)
Impact Resistance B-rated (medium energy impact; 6mm, 0.86g ball traveling at 270mph/430kph)
Lens Coatings Anti-scratch (K-rated), Anti-mist (N-rated)
UV Protection 2C-1.2 (UV filter with high light transmission and unimpaired color perception)
Ventilation Vented design for increased airflow
Accessory Slots Universal slots for various accessories
Weight Approximately 460g
Size Range 53 - 64 cm

Applications

The EVO VISTAlens Safety Helmet is ideal for use in:

  • Construction and building sites
  • Industrial and manufacturing facilities
  • Warehousing and logistics operations
  • Utilities and maintenance work
  • Mining and excavation activities
  • Oil and gas industries
  • Any environment requiring head and eye protection

Maintenance and Care

To ensure the longevity and effectiveness of the EVO VISTAlens Safety Helmet:

  • Clean the helmet and eyewear regularly with mild soap and water; avoid abrasive cleaners or solvents.
  • Store the helmet away from direct sunlight and extreme temperatures.
  • Inspect the helmet and eyewear before each use for signs of damage or wear; replace if necessary.
  • Do not apply unauthorized paint, stickers, or labels as these may compromise the helmet's integrity.
